A Beginner’s Guide To Building Shareable React Components, Part 2: Planning

Photo by Johannes Plenio on Unsplash

Welcome to Part 2 of A Beginner’s Guide To Building Shareable React Components Series. In Part 1 of this series**,** I wrote about the theory behind planning sharable react components.

A Beginner’s Guide To Building Shareable React Components, Part 1: Theory _A solid plan leads to a solid foundation_nategeslin.medium.com

Today, we’re going to put that theory to work and plan out a sharable react component!

Caveats

I’ll add the same caveats here as I did in Part 1. I’m not a designer. I like to think I have a good eye for design, but I can’t design my way out of a cardboard box. I’m an engineer.

This is something of a non-sensical component. We’re going to use it here to help illustrate how we might plan this out.

Since we’re living in a bit of a fantasy world with this exercise, let’s also assume the following:

The scope of this component is two different areas of an app
We don’t know if there are plans to use this elsewhere, but it’s possible
The project we are building this for is small, but growing
There are some shared components built already
We assume there are many more components to come, but as of yet maybe only 20 or so are built

Brief

Here is what we’re going to be planning.

This super-awesome-totally-practical component can be found on Figma. This design includes enough information for us to start planning things out. There are some gaps here, though, and we will likely end this process with some assumptions and some questions.

It’s okay that we don’t/won’t have all the answers at this stage. Remember we are planning, we are not building (yet). There is still time for designs to change.

Okay, let’s get started!

Flexibility

The very first thing I see with this design is that it looks like we have two main variations.

Two variations of our component

Variation #1 is a basic card. Pretty straightforward, a title, an image, some copy, and a Read More link. It also looks like there is some truncation happening there.

Variation #2 appears to be an interactive accordion. When expanded, the accordion looks nearly identical to the basic card.

Variation #1 (left) without a trigger, and variation #2 (right) with an accordion trigger

Decision point: Do we build two components or do we build one to handle both cases?

For now, since we’re moving fast and the use-case for this component is relatively small, we’re going to build a single component. However, our artifacts are going to call this decision out. That in the future we may want to split this up.

Boundaries

This is a pretty basic component, at least on the surface. Most of what this component needs, we can assume, will be supplied from a parent. The accordion part is an important part to decide on, though. Should that be controlled by a parent or not?

Personally, I think it makes sense to control that from within the component itself. However, we should expose a prop that would allow for defaulting an open state on render.

interface IProps {
  isExpanded?: boolean
}

We can make this optional since we might not always need it. The component will take over control of that prop (and subsequent state value) after the first render.

Layout

Do we want Loose Boundaries or Rigid Requirements? To me, this looks like a Rigid Requirements component.

There is a very specific layout required here, with very specific contents. This makes it easy for us to expose simple props and control everything else from within the component.

Should we assume we will always have a title, image, caption, and read more link? What happens if we do not have those things? This feels like a question for UX. In the mean time, we can plan to make those required props.

Component Internals

Let’s take a look at our design variations and see if we can’t break this down into something that looks like a component API.

Mapping sections of this component to possible props or state

I’ve highlighted the areas we care about here in pink. Some of this may be obvious while some may not.

We talked above about what should be considered required. But now that we are looking at the design, there might be another question or two. Should the Read More link be configurable? Will that always be Read More? Will it always be a link*?*

For now, we can make a few decisions:

No, it will not be configurable
Yes, it will always be Read More
Yes, it will always be a link

We can also assume that if either of these were to change in the future, we may want to consider accepting JSX. That would move the footer section of the component from Rigid Requirements to Loose Boundaries. Which, by the way, is totally acceptable!

So what does our API look like? How about something like this:

interface IProps {
  articleUrl: string
  caption: string
  imageUrl: string
  isAccordion?: boolean
  isExpanded?: boolean
  title: string
}

// state
// isOpen: boolean

One other consideration to think about here. Occasionally, it’s useful to bubble events up to parent components. Sometimes there are side effects that a parent will manage that the child should not. Other times the parent needs access to the event for one reason or another.

If we wanted to bubble the event, our contract changes slightly to:

interface IProps {
  articleUrl: string
  caption: string
  imageUrl: string
  isAccordion?: boolean
  isExpanded?: boolean
  onClickAccordionTrigger: (event: React.SyntheticEvent) => void
  title: string
}

// state
// isOpen: boolean

// should call props.onClickAccordionTrigger() with `event` setIsOpen()

Tests

For some, this is the hardest part. When you are first getting into planning, it’s hard to know what someone else might need to build something. This, like anything, gets easier with practice.

In Part 1 we talked about producing something close to Gherkin. Personally, I tend to end up with something looks like gherkin, just a little less formal. I wrote about my variation in Write Tests With Sentences First, Code Second.

Write Tests With Sentences First, Code Second _Don’t dive right in, first write an outline then translate that to code_javascript.plainenglish.io

So, what does that look like for what we’re planning?

when passed required props
    then title should be visible
        then the trigger icon should not be visible
            and image should be visible
            and caption should be visible
            and read more should link to articleUrl

    when isAccordion passed as false
        then the trigger icon should not be visible
            and image should be visible
            and caption should be visible
            and read more should link to articleUrl

    when isAccordion is passed as true
        and isExpanded is passed false
            then the trigger icon should use down variation
                and the image should not be visible
                and the caption should not be visible
                and the read more link should not be visible

            and accordionTrigger is clicked
                then the trigger icon should use the up variation
                    and the image should be visible
                    and the caption should be visible
                    and the read more link should be visible

            and isExpanded is passed true
                then the trigger icon should use up variation
                    and the image should be visible
                    and the caption should be visible
                    and the read more link should be visible

        and accordionTrigger is clicked
            then the trigger icon should use down variation
                and the image should not be visible
                and the caption should not be visible
                and the read more link should not be visible

Photo by The Digital Marketing Collaboration on Unsplash

Artifacts

We made it! We’ve gone through the designs, asked some questions, formulated some assumptions, and created a first draft of an api. We’re ready to hand this off and move on to the next phase.

Congratulations!

Let’s review what we ended up with, we’re going to need these later in an article-to-follow.

Props

interface IProps {
  articleUrl: string
  caption: string
  imageUrl: string
  isAccordion?: boolean
  isExpanded?: boolean
  // depends on if we want to bubble the event
  onClickAccordionTrigger: (event: React.SyntheticEvent) => void
  title: string
}

State

// state

isOpen: boolean

// should call props.onClickAccordionTrigger() with `event`setIsOpen()

Expectations

when passed required props
    then title should be visible
        then the trigger icon should not be visible
            and image should be visible
            and caption should be visible
            and read more should link to articleUrl

    when isAccordion passed as false
        then the trigger icon should not be visible
            and image should be visible
            and caption should be visible
            and read more should link to articleUrl

    when isAccordion is passed as true
        and isExpanded is passed false
            then the trigger icon should use down variation
                and the image should not be visible
                and the caption should not be visible
                and the read more link should not be visible

            and accordionTrigger is clicked
                then the trigger icon should use the up variation
                    and the image should be visible
                    and the caption should be visible
                    and the read more link should be visible

            and isExpanded is passed true
                then the trigger icon should use up variation
                    and the image should be visible
                    and the caption should be visible
                    and the read more link should be visible

        and accordionTrigger is clicked
            then the trigger icon should use down variation
                and the image should not be visible
                and the caption should not be visible
                and the read more link should not be visible

Assumptions and Questions

articleUrl, caption, imageUrl, and title props are all required and should always be passed
When present, the accordion trigger will always be on the right side
The accordion trigger will always use the same icon defined internally
Read More will always be a link
Read More will not be configurable

Future Considerations

We might want to split this component in two to allow for a slimmer Card component
We might update the footer to accept JSX, which give implementors complete control over the Read More link by overriding it entirely

Conclusion

We’ve done the work, we’ve made some decisions, and we’ve set up a blueprint. All that is left now is to actually build (and test) the thing!

Okay, It’s not quite that simple. We have done a lot of good work though. The engineer that ends up doing this work is going to be starting out on the right foot.

Coincidentally, the engineer that ends up doing the work will be me (us), in a link-to-future-part-3-article.

Thank you for reading!
